5 Series B MSO Mixed Signal Oscilloscope

Get a complete view of your design with high-fidelity waveforms, insightful measurements, unique spectrum analysis, and flexible probing. Experience the intuitive user interface appreciated by engineers everywhere.

Base Price
US $22,400 +
Select Model to Configure/Quote
Product Overview Datasheet Manual Downloads
Bandwidth

Up to 2 GHz

Record length

Up to 500 M

Analog channels

4 or 6 or 8

Vertical Resolution

12 bits

5 Series B MSO

Get to know the 5 Series B

Performance for today and tomorrow

Intuitive controls

Insightful measurements and analysis

Multi-channel spectrum analysis with the 4, 5 or 6 Series MSOs

Get to know the 5 Series B

  • Performance for today and tomorrow
  • Intuitive controls
  • Insightful measurements and analysis
  • Multi-channel spectrum analysis with the 4, 5 or 6 Series MSOs

Insightful measurements

See signal details with high-resolution 12-bit analog-to-digital converters. Change your point of view whenever you wish with multi-channel spectrum analysis, measurement statistics, tables and trend plots.

  • 12-bit resolution at 1.25 GHz; 16-bit resolution at 50 MHz
  • Built-in DDCs enable multi-channel, synchronized spectrum analysis
  • Results tables, measurement statistics, histograms, and trend plot views
5 Series B MSO - Insightful Measurements
5-series B MSO - Advanced Solutions

Advanced solutions

The 5 Series adapts to suit your needs with a wide range of application-specific measurements. Add advanced analysis packages individually or install application bundles to address more diverse workloads.

  • Support for over 25 serial protocols covering the most common interfaces
  • Advanced single-phase and three-phase power analysis packages
  • Measurement tools for signal integrity and power integrity
  • Optional Windows® operating system lets you run PC software

Learn about available analysis upgrades

More ways to see more signals

Versatile inputs and advanced probing technology let you see more.

  • Up to 8 FlexChannel™ inputs for up to 8 analog or 64 digital signals, plus an external trigger input
  • Includes 500 MHz or 1 GHz probes with just 3.9 pF input capacitance
  • TekVPI probe interface supports a wide range of active, differential, isolated and current probes
5-series B MSO - More Ways to See More Signals

Specification Overview

Input Channels
4,6 or 8 FlexChannel inputs.
Each FlexChannel provides 1 analog signal input or 8 digital logic inputs with TLP0581 probe
NEW Auxiliary trigger input

Bandwidth 1
350 MHz, 500 MHz, 1 GHz, 2 GHz

Sample Rate
6.25 GS/s

Record Length 1
Up to 500 Mpoints on all analog/digital channels

Internal Data Storage 1
NEW 250 GB removable SSD

Protocol Decode 1
Over 25 protocols available

Signal Generator 1
13 standard waveform types, plus arbitrary
NEW 100 MHz maximum frequency

Digital Voltmeter 2
4 digit

Trigger Frequency Counter 2
8 digit

Display
15.6-inch (385 mm)
TFT color HD (1920 x 1080) resolution capacitive (multi-touch) touchscreen

1 - Optional and upgradeable
2 - Free with product registration

Differences between the 5 Series B MSO and the 5 Series MSO
Included probes and accessories

5 Series B MSO Specifications

Work and collaborate almost anywhere

Capture data outside the lab and collaborate easily with engineers on the next bench or in the next time-zone.

  • Using just a web browser, connect and control the scope within your own network
  • Analyze data on or off the scope with TekScope™ PC analysis software that works just like the scope
  • Optional TekDrive one-button cloud storage facilitates record-keeping and collaboration
  • Analyze data on or off the scope with TekScope™ PC analysis software that works just like the scope
  • TekHSI high speed interface offers much faster data transfer from your instrument to your PC

Work and collaborate almost anywhere

TekScope Remote Work
Model Analog Bandwidth Sample Rate Record Length Analog Channels Digital Channels Function Generator Output List Price Configure And Quote
MSO54B 350 MHz - 2 GHz 6.25 GS/s 62.5 M - 500 M 4 Up to 32 (optional)

1 (optional)

 US $22,400 Configure & Quote
MSO56B 350 MHz - 2 GHz 6.25 GS/s 62.5 M - 500 M 6 Up to 48 (optional)

1 (optional)

 US $27,500 Configure & Quote
MSO58B 350 MHz - 2 GHz 6.25 GS/s 62.5 M - 500 M 8 Up to 64 (optional)

1 (optional)

 US $37,200 Configure & Quote
Model Analog Bandwidth Sample Rate Record Length Analog Channels Digital Channels Function Generator Output List Price Configure And Quote
MSO54B 350 MHz - 2 GHz 6.25 GS/s 62.5 M - 500 M 4 Up to 32 (optional)

1 (optional)

 US $22,400 Configure & Quote
MSO56B 350 MHz - 2 GHz 6.25 GS/s 62.5 M - 500 M 6 Up to 48 (optional)

1 (optional)

 US $27,500 Configure & Quote
MSO58B 350 MHz - 2 GHz 6.25 GS/s 62.5 M - 500 M 8 Up to 64 (optional)

1 (optional)

 US $37,200 Configure & Quote
  Tektronix
5 Series B MSO		 Tektronix
MSO/DPO5000B		 Keysight
EXR		 LeCroy
WaveRunner8000HD		 Rohde & Schwarz
RTO2000		 Yokogawa
DLM4000 Series
Detailed Comparison -- -- -- -- Fact Sheet Fact Sheet
Bandwidth 350 MHz to 2 GHz 350 MHz to 2 GHz 500 MHz to 2.5 GHz 350 MHz to 2 GHz 600 MHz to 6 GHz 350 MHz, 500 MHz
Upgradeable Bandwidth Yes No Yes No Yes No
Analog Channels 4, 6, or 8 4 4 or 8 8 2 or 4 8
Analog Sample Rate (All Channels) Up to 6.25 GS/s Up to 5 GS/s Up to 16 GS/s Up to 10 GS/s Up to 10 GS/s 2.5 GS/s
Standard Record Length (All Channels) 62.5 M 25 M 100 M 50 M 50 M 25 M
Integrated Arbitrary/Function Generator 100 MHz (opt.) No 50 MHz (opt.) No 100 MHz (opt.) No
Digital Channels (MSO) Up to 64 (opt.) 16 (opt.) 16 (opt.) 16 (opt.) 16 (opt.) 8 (std) / 24 (opt)
ADC Resolution 12-bits 8-bits 10-bits 12-bits 8-bits 8-bits
Waveform Capture Rate >500,000 wfms/sec 250,000 wfms/sec TBD TBD 1,000,000 wfms/sec N/A
Operating System Closed Linux
Open Windows (opt.)		 Open Windows Open Windows Open Windows Open Windows Closed
Standard Probes Up to 1 GHz Passive
< 3.9 pF Loading		 Up to 1 GHz Passive
< 3.9 pF Loading		 500 MHz Passive
9.5 pF loading		 500 MHz Passive
10 pF loading		 500 MHz Passive
10 pF loading		 500 MHz
10.5 pF loading
5-series B MSO - Protocol Decode Analysis

Protocol Decoding and Analysis

Automatic serial bus decoding saves time and eliminates errors versus hand decoding. Search functions enable you to isolate events for fast system-level troubleshooting. See the datasheet for a complete listing of more than 25 supported protocols.

Highlights

  • I2C, SPI
  • RS-232 / 422 / 485 / UART
  • USB 2.0
  • Ethernet

Overview of Protocol Decoding and Analysis

Discover the Embedded Design Reference Solution

Power Integrity and Power Management

Today’s boards can have 20 or more power rails. Most of these are just a few volts or less and many have strict noise limits. Make accurate multi-rail measurements with the right tools .

Highlights

  • Up to 8 analog input channels
  • Compatible with low-noise TPR Series power-rail probes
  • Decoding options for I2C, SPI, SMBus, SPMI and SVID
  • Optional impedance vs. frequency plots

Learn how to decode and trigger on the SPMI power management bus

Learn how more channels simplify power supply sequencing

Measuring Ripple and Noise on Power Rails

Discover the Power Integrity Analysis Reference Solution

5-series B MSO - Power Integrity and Power Management
Jitter Analysis

Jitter Analysis and Serial Standards Compliance

Clocks are the heart of every embedded system and digital communication link. Excessive jitter can impact system operation but the jitter analysis package will help you find the sources.

Automated compliance packages simplify testing to make sure your high-speed serial bus implementations conform to serial standards such as USB and Ethernet.

Learn the basics of jitter analysis

Learn how to use the 5 Series MSO for jitter analysis

Power Supply Analysis

Whether your latest design uses silicon, gallium arsenide or silicon carbide, making accurate power quality, harmonics and switching loss measurements is easier with automated power measurements.

Highlights

  • Power quality and harmonics
  • Switching loss and safe operating area
  • In-circuit inductor and transformer analysis
  • Multi-output efficiency
  • Bode plots and power supply rejection ratio

Learn how to make automated switching loss measurements, harmonics measurements, and more

Measuring Switching Loss on SiC Power Supplies with a 5 Series B MSO

Discover the Wide Bandgap Double Pulse Reference Solution

5-series B MSO - Power Supply Analysis
3-phase Inverters, Motors and Drives

3-Phase Inverters, Motors and Drives Analysis

Make stable 3-phase power measurements on pulse-width modulated waveforms. The Inverters, Motors and Drives Analysis package makes it easy.

Highlights

  • Up to 8 analog input channels
  • 3-phase wye, delta, and single-phase wiring configurations
  • Comprehensive power measurements
  • Harmonics analysis
  • DQ0 measurements
  • Mechanical measurements include angle, speed, acceleration and torque

Learn how to make measurements on 3-phase motor drives

Discover the EV Traction Inverter Analysis Reference Solution

Automotive Power and In-vehicle Networks

Equipped with differential voltage probes and current probes, the 5 Series is ideal for validating the latest SiC power converters.

Decoders for CAN, CAN FD, LIN, FlexRay, PSI5 and SENT buses make it easy to see communications between ECUs, sensors and actuators.

An automated Automotive Ethernet compliance suite lets you easily test to the standards, without becoming a high-speed bus expert.

Learn about making measurements on silicon carbide (SIC) power converters

Learn how CAN, CAN FD, LIN and FlexRay decoding and triggering speed debug

Learn about the automated Automotive Ethernet Test Solution

5-series B MSO - Automotive Power and In-vehicle Networks
Remote Control and Automation

Remote Control and Automation

Get fast, repeatable results and access your data from anywhere. Automate your testing with confidence.

  • TekScope PC Software offers the same analysis capability available on Tektronix oscilloscopes, on your PC. It supports the new TekHSI high speed interface for much faster data transfers to your PC
  • KickStart Software simplifies data capture and logging. Supports function generators, power supplies, SMUs and more
  • Built-in *eScope or Windows Remote Desktop let you control your scope over any LAN
  • Comprehensive, fully-supported programming interfaces enable development of robust custom software
  • Discover test automation resources including the free Python Drivers Package

Learn about tools for remote work and collaboration

Electromagnetic Interference (EMI) Troubleshooting

Each analog channel on the 5 Series B MSO can show you a time domain waveform, a spectrum, or both. Time and frequency plots are synchronized to help you quickly determine which signals are the victims and which ones are the aggressors.

Learn about EMI troubleshooting

Electromagnetic Interference Troubleshooting

Starter

US $2,400

Subscription

US $6,030

Perpetual

Select license option to continue

Purchase a License
  • Serial trigger, decode, search and event table analysis on I2C, SPI, RS-232/422/485/UART buses
  • Integrated Arbitrary/Function Generator with 13 predefined waveform types as well as arbitrary waveforms
  • Power Measurement and Analysis

Learn about maintenance for software and licenses

View Brochure

Average Savings of 58%!

Get a Free Trial
Questions? Contact Us

Pro

  • Includes Starter Bundle
  • Adds 125M/ch record length

Purchase a Pro or Ultimate software bundle and get 12 months of maintenance included.

View Brochure

Average Savings of 76%!

PLUS: Choose a bundle

Questions? Contact Us

Automotive

US $6,330

Subscription

US $15,600

Perpetual

  • Advanced jitter analysis
  • Automotive Ethernet PAM3 analysis*
  • Automotive Ethernet signal separation*
  • Automotive Ethernet compliance*
  • Inverter & motor drive analysis
  • Double pulse testing
  • 100BASE-T1 decoding
  • CAN, CAN FD,
    CAN XL decoding
  • CXPI decoding
  • FlexRay decoding
  • I3C decoding
  • LIN decoding
  • PSI5 decoding
  • SENT decoding
  • Power Measurement and Analysis

Select license option to continue

Purchase a License
Get a Free Trial

Compliance

US $5,710

Subscription

US $14,300

Perpetual

  • 10/100/100BASE-T Ethernet with Multi-lane*
  • 10BASE-T1L Industrial Ethernet*
  • USB 2.0
  • Power Measurement and Analysis
  • DJA

Select license option to continue

Purchase a License
Get a Free Trial

Aerospace

US $6,030

Subscription

US $15,400

Perpetual

  • Advanced jitter analysis
  • Mask/limit testing
  • ARINC 429 decoding
  • MIL-STD-1553 decoding
  • NRZ decoding
  • SpaceWire decoding
  • Power Measurement and Analysis

Select license option to continue

Purchase a License
Get a Free Trial

Power

US $5,710

Subscription

US $14,500

Perpetual

  • Advanced power analysis
  • Digital power management analysis
  • Double pulse testing
  • SPMI decoding
  • SVID decoding
  • TDR measurements
  • Inverter & motor drive analysis with DQ0 and mechanical measurements

Select license option to continue

Purchase a License
Get a Free Trial

Serial Decode

US $5,710

Subscription

US $14,300

Perpetual

  • 1-Wire
  • 8b10b
  • Audio
  • CAN, CAN FD,
    CAN XL
  • CXPI
  • EtherCAT
  • Ethernet
  • eSPI
  • eUSB
  • FlexRay
  • I3C
  • LIN
  • Manchester
  • MDIO
  • MIPI C-PHY
  • MIPI D-PHY
  • NFC
  • NRZ
  • SDLC
  • SMBus
  • SPMI
  • SVID
  • USB 2.0
  • Power Measurement and Analysis

Select license option to continue

Purchase a License
Get a Free Trial

Signal Integrity

US $6,030

Subscription

US $15,400

Perpetual

  • Advanced jitter analysis
  • LVDS debug*
  • Mask/limit testing
  • PAM3 analysis*
  • User-Defined Filters
  • Power Measurement and Analysis

Select license option to continue

Purchase a License
Get a Free Trial

Ultimate

US $11,400

Subscription

US $28,100

Perpetual

Select license option to continue

Purchase a License
  • Includes Starter bundle and all Pro bundles
  • PLUS: 500 M/ch record length, Spectrum View RF vs. time waveforms, extended Spectrum View capture bandwidth, and video triggers

Purchase a Pro or Ultimate software bundle and get 12 months of maintenance included.

View Brochure

Average Savings of 91%!

Get a Free Trial
Questions? Contact Us
Back to bundles

Individual Options

Questions? Contact Us

  • Opt. 5-AFG

    Add built-in Arbitrary/Function Generator

  • Opt. 5-AUTOEN-BND

    Automotive Ethernet Compliance, Signal Separation, PAM3 Analysis (requires Option 5-DJA), 100BASE-T1 Serial Decode (bundle option)

  • Opt. 5-AUTOEN-SS

    Automotive Ethernet Signal Separation

  • Opt. 5-CMAUTOEN

    Automotive Ethernet (100Base-T1 and 1000BASE-T1) automated compliance test solution

  • Opt. 5-CMAUTOEN10

    Automotive Ethernet (10Base-T1S Short Reach ) automated compliance test solution

  • Opt. 5-CMENET

    Ethernet (10/100/1000BASE-T) compliance test solution

  • Opt. 5-CMENETML

    Multilane Ethernet (10BASE-T, 100BASE-T, 1000BASE-T) automated compliance testing for 5 Series MSO, requires 5-CMENET and 5-WIN

  • Opt. 5-CMINDUEN10

    Industrial Ethernet (10Base-T1L Long reach) automated compliance test solution

  • Opt. 5-CMUSB2

    USB 2.0 automated pre-compliance test solution.

  • Opt. 5-DBLVDS

    Automated LVDS test solution for 5 Series MSO oscilloscopes

  • Opt. 5-DJA

    Simplifies identifying signal integrity concerns, jitter and their related sources and provides the highest sensitivity and accuracy available for real-time oscilloscopes.

  • Opt. 5-DPM

    Digital Power Management

  • Opt. 5-DPMBAS

    Basic Digital Power Management Analysis

  • Opt. 5-IMDA

    Inverters, motors and drives analysis

  • Opt. 5-IMDA-DQ0

    DQ0 analysis for Inverters, Motors and Drives

  • Opt. 5-IMDA-MECH

    Mechanical measurements for Inverters, Motors and Drives

  • Opt. 5-MTM

    Mask Testing

  • Opt. 5-PAM3

    PAM3 Analysis

  • Opt. 5-PS2

    Power Solution Bundle (5-PWR, THDP0200, TCP0030A, 067-1686-XX (deskew fixture))

  • Opt. 5-PWR

    Power measurement and analysis

  • Opt. 5-RFNFC

    NFC wireless protocol decoding and search

  • Opt. 5-RL-125M

    Extend record length to 125 Mpts / channel

  • Opt. 5-RL-250M

    Extend record length to 250 Mpoints/channel

  • Opt. 5-RL-500M

    Extend record length to 500 Mpoints/channel

  • Opt. 5-SR8B10B

    8b10b Protocol Decoder and Search

  • Opt. 5-SRAERO

    Aerospace serial triggering and analysis

  • Opt. 5-SRAUDIO

    I2S, LJ, RJ, and TDM protocol trigger and decode of serial packet content

  • Opt. 5-SRAUTO

    CAN, CAN FD, CAN XL, LIN and FlexRay protocol trigger and decode of serial packet content

  • Opt. 5-SRAUTOEN1

    100BASE-T1 Protocol Decode

  • Opt. 5-SRAUTOSEN

    Automotive sensor serial triggering and analysis

  • Opt. 5-SRCOMP

    RS-232/422/485/UART protocol trigger and decode of serial packet content

  • Opt. 5-SRCPHY

    MIPI C-PHY decoding and analysis

  • Opt. 5-SRCXPI

    CXPI protocol decoding and analysis

  • Opt. 5-SRDPHY

    MIPI D-PHY (CSI/DSI) decoding and analysis

  • Opt. 5-SREMBD

    I2C and SPI protocol trigger and decode of serial packet content

  • Opt. 5-SRENET

    10BASE-T and 100BASE-TX protocol search and decode of serial packet content

  • Opt. 5-SRESPI

    eSPI protocol decoding and analysis

  • Opt. 5-SRETHERCAT

    EtherCAT protocol decoding and analysis

  • Opt. 5-SREUSB2

    eUSB2 protocol decoding and analysis

  • Opt. 5-SRI3C

    MIPI I3C decoding and analysis

  • Opt. 5-SRMANCH

    Manchester decoding and analysis

  • Opt. 5-SRMDIO

    MDIO protocol decoding and analysis

  • Opt. 5-SRNRZ

    NRZ Protocol Decoder and Search

  • Opt. 5-SRONEWIRE

    1-Wire protocol decoding and analysis

  • Opt. 5-SRPM

    SPMI Power Management serial triggering and analysis

  • Opt. 5-SRPSI5

    PSI5 serial decode and analysis

  • Opt. 5-SRSDLC

    Synchronous data link control (SDLC) decoding and analysis

  • Opt. 5-SRSMBUS

    SMBus protocol decoding and analysis

  • Opt. 5-SRSPACEWIRE

    SpaceWire protocol decoding and analysis

  • Opt. 5-SRSVID

    SVID protocol decoding and analysis

  • Opt. 5-SRUSB2

    USB 2.0 Low-Speed, Full-Speed, and High-Speed protocol trigger and decode of serial packet content

  • Opt. 5-SV-BW-1

    Increase Spectrum View Capture Bandwidth to 500 MHz

  • Opt. 5-SV-RFVT

    Spectrum View RF versus time analysis and trigger

  • Opt. 5-TDR

    Time domain reflectometry (TDR) measurements and analysis

  • Opt. 5-UDFLT

    User-defined filter creation tool

  • Opt. 5-VID

    Analog Video Trigger(NTSC, PAL, SECAM)

  • Opt. 5-WBG-DPT

    Wide bandgap (SiC/GaN) double pulse test application

  • Opt. 5-WIN

    Add solid state drive with Windows 10 license

* Indicates features that require 5-WIN

Access Digital Channels

Upgrade Description Purchasing Details
TLP058 Logic Probe Each probe accesses 8 digital channels on any FlexChannel for any 5 Series MSO Request a quote on this probe

Add Instrument Functions

Upgrade Description Purchasing Details
SUP5-AFG Add arbitrary function generator Request trial license

Request a quote
SUP5-DVM Add digital voltmeter / trigger frequency counter Software upgrade license file provided upon registration.
Register now.
SUP5-RL-125M Extend record length to 125 Mpts / channel Request trial license

Request a quote
SUP5-RL-250M Extend record length to 250 Mpts / channel Request trial license

Request a quote
SUP5-RL-500M Extend record length to 500 Mpts / channel Request trial license

Request a quote
SUP5B-LNX Add removable solid-state drive with embedded operating system No trial available

Request a quote
SUP5B-WIN Add removable solid-state drive with Windows 10 license installed No trial available

Request a quote

Add Protocol Analysis

Upgrade Description Purchasing Details
SUP5-RFNFC NFC wireless protocol decoding and search Request trial license

Request a quote
SUP5-SR8B10B 8b10b Protocol Decoder and Search Request trial license

Request a quote
SUP5-SRAERO Aerospace serial triggering and analysis (MIL-STD-1553, ARINC429) Request trial license

Request a quote
SUP5-SRAUDIO Audio serial triggering and analysis (I2S, LJ, RJ, TDM) Request trial license

Request a quote
SUP5-SRAUTO Automotive serial triggering and analysis (CAN, CAN FD, CAN XL, LIN, FlexRay) Request trial license

Request a quote
SUP5-SRAUTOEN1 100BASE-T1 automotive Ethernet protocol decode software Request trial license

Request a quote
SUP5-SRAUTOSEN Automotive sensor serial triggering and analysis (SENT) Request trial license

Request a quote
SUP5-SRCOMP Computer serial  triggering and analysis (RS-232/422/485/UART) Request trial license

Request a quote
SUP5-SRCPHY MIPI C-PHY protocol decoding and analysis Request trial license

Request a quote
SUP5-SRCXPI CXPI protocol decoding and analysis Request trial license

Request a quote
SUP5-SRDPHY MIPI D-PHY (CSI/DSI) decoding and analysis Request trial license

Request a quote
SUP5-SREMBD Embedded serial triggering and analysis (I2C, SPI) Request trial license

Request a quote
SUP5-SRENET Ethernet serial triggering and analysis (10Base-T, 100Base-TX) Request trial license

Request a quote
SUP5-SRESPI eSPI protocol decoding and analysis Request trial license

Request a quote
SUP5-SRETHERCAT EtherCAT protocol decoding and analysis Request trial license

Request a quote
SUP5-SREUSB2 eUSB2 protocol decoding and analysis Request trial license

Request a quote
SUP5-SRI3C MIPI I3C decoding and analysis Request trial license

Request a quote
SUP5-SRMANCH Manchester decoding and analysis Request trial license

Request a quote
SUP5-SRMDIO MDIO protocol decoding and analysis Request trial license

Request a quote
SUP5-SRNRZ NRZ Protocol Decoder and Search Request trial license

Request a quote
SUP5-SRONEWIRE 1-Wire protocol decoding and analysis Request trial license

Request a quote
SUP5-SRPM Power Management serial triggering and analysis (SPMI) Request trial license

Request a quote
SUP5-SRPSI5 PSI5 serial decode and analysis Request trial license

Request a quote
SUP5-SRSDLC Synchronous Data Link Control (SDLC) decoding and analysis Request trial license

Request a quote
SUP5-SRSMBUS SMBus protocol decoding and analysis Request trial license

Request a quote
SUP5-SRSPACEWIRE SpaceWire protocol decoding and analysis Request trial license

Request a quote
SUP5-SRSVID SVID protocol decoding and analysis Request trial license

Request a quote
SUP5-SRUSB2 USB 2.0 serial bus triggering and analysis (LS, FS, HS) (≥ 1 GHz model recommended for HS) Request trial license

Request a quote

Add Serial Compliance Testing

Upgrade Description Purchasing Details
SUP5-CMAUTOEN Automotive Ethernet (100Base-T1 and 1000BASE-T1) automated compliance test solution Request trial license

Request a quote
SUP5-CMAUTOEN10 Automotive Ethernet (10BASE-T1S Short Reach) automated compliance test solution Request trial license

Request a quote
SUP5-CMUSB2 USB 2.0 automated pre-compliance test solution Request trial license

Request a quote
SUP5-CMENET Ethernet (10/100/1000BASE-T) compliance test solution Request trial license

Request a quote
SUP5-CMENETML Multilane Ethernet (10BASE-T, 100BASE-T, 1000BASE-T) automated compliance testing for 5 Series MSO, requires 5-CMENET and 5-WIN Request trial license

Request a quote
SUP5-DBLVDS Automated LVDS test solution for 5 Series MSO oscilloscopes Request trial license

Request a quote
SUP5-AUTOEN-BND Automotive Ethernet Compliance, Signal Separation, PAM3 Analysis, 100BASE-T1 Decode software Request trial license

Request a quote
SUP5-AUTOEN-SS Signal Separation Solution (Min BW 1 GHz) using TekExpress Automation Platform Request trial license

Request a quote
SUP5-CMINDUEN10 Industrial Ethernet (10Base-T1L Long reach) automated compliance test solution Request trial license

Request a quote
SUP5-PAM3 PAM3 Automated Compliance Solution (Min BW 1 GHz) using TekExpress Automation Platform Request trial license

Request a quote

Add Advanced Analysis

Upgrade Description Purchasing Details
SUP5-DPM Complete Digital Power Management Analysis and debug solution (Includes all measurements in DPMBAS + Jitter Analysis and Eye Diagram Analysis) Request trial license

Request a quote
SUP5-DPMBAS Basic Digital Power Management Analysis and Debug Solution (includes Power Sequence Analysis, Transient Analysis and Ripple Analysis) Request trial license

Request a quote
SUP5-DJA Advanced jitter and eye analysis Request trial license

Request a quote
SUP5-IMDA Inverters, motors and drives analysis Request trial license

Request a quote
SUP5-IMDA-DQ0 DQ0 analysis for Inverters, Motors and Drives Request trial license

Request a quote
SUP5-IMDA-MECH Mechanical measurements for Inverters, Motors and Drives Request trial license

Request a quote
SUP5-MTM Mask and limit testing Request trial license

Request a quote
SUP5-PWR Power analysis Request trial license

Request a quote
SUP5-SV-BW-1 Spectrum View Capture Bandwidth to 500 MHz Request trial license

Request a quote
SUP5-SV-RFVT Spectrum View RF versus time analysis and trigger Request trial license

Request a quote
SUP5-TDR Time domain reflectometry (TDR) measurements and analysis Request trial license

Request a quote
SUP5-UDFLT User-defined filter creation tool Request trial license

Request a quote
SUP5-VID Analog video trigger (NTSC, PAL, SECAM) Request trial license

Request a quote
SUP5-WBG-DPT Wide bandgap (SiC/GaN) double pulse test application Request trial license

Request a quote

Upgrade Bandwidth

Upgrade Description Purchasing Details
SUP5B-BW4 Bandwidth upgrade for 5 Series B MSO with 4 FlexChannel inputs. See datasheet for options.
  • Up to 1 GHz upgrades can be performed in the field.
  • 2 GHz upgrade requires installation at a Tektronix Service Center via option IFC or IFCIN.
  • Bandwidth upgrades from 350 or 500 MHz, to 1 or 2 GHz also include one TPP1000 1 GHz passive probe per channel.
SUP5B-BW6 Bandwidth upgrade for 5 Series B MSO with 6 FlexChannel inputs. See datasheet for options.
SUP5B-BW8 Bandwidth upgrade for 5 Series B MSO with 8 FlexChannel inputs. See datasheet for options.
Current Probes
Datasheet Link Probe Description Configure and Quote
View Datasheet TCP0020 Probe, AC/DC Current; 20 Amp; 50 MHz BW; TekVPI Interface; Certificate of Traceable Calibration Standard Configure & Quote
View Datasheet TCP0030A Probe, AC/DC Current; 30 Amp DC, DC TO 120 MHZ; with TekVPI Interface; Certificate of Traceable Calibration Standard Configure & Quote
View Datasheet TCP0150 Current Probe: 20 MHz, 5 mA to 212 A, AC/DC, TekVPI Configure & Quote
High Voltage Differential Probes
Datasheet Link Probe Description Configure and Quote
View Datasheet TDP0500 Differential Probe: 500 MHz, 5X/50X, +/- 42V, TekVPI Configure & Quote
View Datasheet TDP1000 Differential Probe: 1 GHz, 5X/50X, +/- 42V, TekVPI Configure & Quote
View Datasheet THDP0100 Differential PROBE; 100 MHZ TekVPI DIFFERENTIAL HIGH VOLTAGE PROBE Configure & Quote
View Datasheet THDP0200 Differential PROBE; 200 MHZ TekVPI DIFFERENTIAL HIGH VOLTAGE PROBE Configure & Quote
View Datasheet TMDP0200 Differential PROBE; 200 MHZ TekVPI DIFFERENTIAL MEDIUM VOLTAGE PROBE;TMPD0200 Configure & Quote
High Voltage Probe: Single-Ended
Datasheet Link Probe Description Configure and Quote
View Datasheet TPP0850 High Voltage Probe: 800 MHz, 50X, 2.5 kV, Single-ended, TekVPI Configure & Quote
IsoVu™ Isolated Current Probes
Datasheet Link Probe Description Configure and Quote
View Datasheet TICP025 250 MHz Tektronix Isolated Current Probe Configure & Quote
View Datasheet TICP050 500 MHz Tektronix Isolated Current Probe Configure & Quote
View Datasheet TICP100 1 GHz Tektronix Isolated Current Probe Configure & Quote
IsoVu™ Isolated Voltage Probes
Datasheet Link Probe Description Configure and Quote
View Datasheet TIVP02 IsoVu Gen. 2 optically isolated differential probe, 200 MHz, TekVPI, 2 m cable, includes 10X (TIVPMX10X) tip Configure & Quote
View Datasheet TIVP02L IsoVu Gen. 2 optically isolated differential probe, 200 MHz, TekVPI, 10 m cable, includes 10X (TIVPMX10X) tip Configure & Quote
View Datasheet TIVP05 IsoVu Gen. 2 optically isolated differential probe, 500 MHz, TekVPI, 2 m cable, includes 10X (TIVPMX10X) tip Configure & Quote
View Datasheet TIVP05L IsoVu Gen. 2 optically isolated differential probe, 500 MHz, TekVPI, 10 m cable, includes 10X (TIVPMX10X) tip Configure & Quote
View Datasheet TIVP1 IsoVu Gen. 2 optically isolated differential probe, 1 GHz, TekVPI, 2 m cable, includes 10X (TIVPMX10X) tip Configure & Quote
View Datasheet TIVP1L IsoVu Gen. 2 optically isolated differential probe, 1 GHz, TekVPI, 10 m cable, includes 10X (TIVPMX10X) tip Configure & Quote
Logic Probe
Datasheet Link Probe Description Configure and Quote
TLP058 8 channel general purpose logic probe for 5 and 6 Series MSO oscilloscopes. Includes accessory kit. Configure & Quote
Low Voltage Differential Oscilloscope Probes
Datasheet Link Probe Description Configure and Quote
View Datasheet TDP1500 Differential Probe: 1.5 GHz, 1X/10X, +/-8.5V, TekVPI Configure & Quote
View Datasheet TDP3500 Differential Probe: 3.5 GHz, 5X, +/- 2V, TekVPI Configure & Quote
View Datasheet TDP4000 4 GHz, Differential Probe with TekVPI interface Configure & Quote
Low Voltage Probes: Single-Ended
Datasheet Link Probe Description Configure and Quote
View Datasheet TAP1500 Active Probe: 1.5 GHz, 10X, Single-ended, TekVPI Configure & Quote
View Datasheet TAP1500L Configure & Quote
View Datasheet TAP2500 Active Probe: 2.5 GHz, 10X, Single-ended, TekVPI Configure & Quote
View Datasheet TAP4000 4 GHz, Single Ended Probe with TekVPI interface Configure & Quote
Passive Probe
Datasheet Link Probe Description Configure and Quote
View Datasheet TPP0500B Passive Probe: 500 MHz, 10X, TekVPI Configure & Quote
View Datasheet TPP0502 Passive Probe: 500 MHz, 2X, TekVPI Configure & Quote
View Datasheet TPP1000 Passive Probe: 1 GHz, 10X, TekVPI Configure & Quote
Power Rail Probes
Datasheet Link Probe Description Configure and Quote
View Datasheet TPR1000 1 GHz, Single-Ended TekVPI Power-Rail Probe with TPR4KIT Standard Accessory Kit Configure & Quote
View Datasheet TPR4000 4 GHz, Single-Ended TekVPI Power-Rail Probe with TPR4KIT Standard Accessory Kit Configure & Quote

Tektronix offers a range of calibration and warranty extension plans for purchase with your instrument to protect and maintain its performance over the years. Benefits include:

  • OEM quality maintenance
  • Priority on-bench service
  • A host of accident protection, loaner program, and other program features
  • A breadth of calibration service levels and options

Invest now to avoid unplanned downtime and expense. Talk to your sales rep about adding a service plan to your instrument purchase.

5 Series

Protect Your Investment, Protect Your Uptime

Configure & Quote


Service Plan Feature		 Total Protection
(Opt. T3, T5)		 Tek Care
(Opt. R3, R5)
Extension of factory warranty
Protection from manufacturer defects
Free factory certified calibration with repair (if necessary)
Free in-country shipping
Priority on-bench service
Coverage of user-caused EOS and ESD damage
Coverage from accidental damage
Coverage from normal wear and tear

Maintain Accuracy, Get Updates, Pass Audits

Configure & Quote


Calibration Features:		 Z540
Calibration1		 ISO 17025
Compliant1		 ISO 17025
Accredited
Certificate of calibration and calibration label designed to meet audit requirements
Firmware updates, if applicable, along with safety and reliability updates ²
OEM procedures for measurements ²
Test data Optional
Calibration record retention
Traceability
Uncertainty analysis
Independent verification by a ISO/IEC accredited organization (with logo on certificate)

Product/Option		 Description
Tektronix Opt. C3 Calibration service 3 years. C3 provides for 2 calibration events during 3 years after shipment.  Includes traceable calibration or functional verification where applicable, for recommended calibrations.  Coverage includes the initial calibration plus 2-years calibration coverage.
Tektronix Opt. C5 Calibration service 5 years. C5 provides for 4 calibration events during 5 years after shipment.  Includes traceable calibration or functional verification where applicable, for recommended calibrations.  Coverage includes the initial calibration plus 4-years calibration coverage.

1 May be ISO 9001 in specific locations.

2 Standard with factory certified service.

Some limits apply, see program terms for details.

Need to Calibrate More than Just Your 5 Series?

See Calibration Services

Tektronix is a leading accredited calibration services provider for all brands of electronic test and measurement equipment, servicing more than 140,000 models from 9,000 manufacturers. With 100+ labs worldwide, Tektronix serves as your single global partner delivering tailored calibration programs with OEM quality at a market price. Onsite, local pickup and delivery, and other options available.

Tektronix Calibration Services
