Accelerating EV Traction Inverter Analysis

Accelerating the analysis of EV traction inverters is crucial for the advancement of electric vehicles. At the core of the EV powertrain, traction inverters and motors play a pivotal role. Enhancements in these subsystems directly translate into improved vehicle range, performance, and cost.

Adoption of SiC power semiconductors is contributing to better efficiency and more compact traction inverters. Control algorithms and motor construction are being optimized to achieve demanding efficiency and cost targets

EV architects are combining new traction inverter designs with different motor designs, creating new hybrid structures uniquely suited to the demands of electric mobility.

Analyzing the performance of EV traction inverters and motors requires sophisticated test instruments and high-power sourcing. Engineers need multichannel mixed signal oscilloscopes with a 3-phase inverter test application that can display PWM motor drive signals, motor voltage, motor current, and phasor diagrams. Engineers also need a reliable high-power bidirectional power supply that can support the voltage, current, and power drawn by the drivetrain and efficiently absorb energy from regenerative braking. This powerful combination provides a complete solution for traction inverter and motor test.

View The Complete Bench Setup

Techniques for Repeatable Inverter Measurements​

Block diagram of electric vehicle traction inverter and motor

Functional blocks of a traction inverter and motor​.

Understanding Inverter and Motor Technology in Electric Vehicles

EVs employ different types of electric motors but they all require the application of PWM voltage signals to the motor stator to develop three sinusoidal currents spaced 120° apart. The modulation of the high-voltage input is usually performed by high-voltage IGBTs or MOSFETs switching at frequencies ranging from 20 to 100 kHz. Designers work hard to minimize energy loss during switching while maintaining safe timing.

Gate drivers are controlled by a microcontroller (MCU) subsystem and determine the timing of the switching devices. The control circuits must be galvanically isolated from the high-voltage sections.

Inverter controllers often use DSP algorithms, such as field-oriented control (FOC), to precisely vary the PWM output. Based on the driver's input and current speed of the motor, the inverter’s MCU controls the angle between the poles of the direct axis of the rotor (D) and the magnetic field, or quadrature axis (Q) to deliver smooth, optimal torque. Sensors such as encoders or resolvers on the motor’s rotor provide feedback on rotor angle.

Supplying the Required Power

With next-gen EVs embracing 800V architecture, and with EV motors drawing hundreds of amps, traction inverter and motor testing requires a high-capacity power supply. EA-10000 Series power supplies address this need with models that can generate up to 30 kW with voltages up to 2000 V or current output up to 1000 A. EA-10000 Series supplies have a “true” autoranging output enabling delivery of full power from 1/3 of the supply’s voltage rating to the maximum voltage rating for testing inverter and motor performance over the discharge cycle of the battery. The bidirectional power supply modules enable testing regenerative braking performance. These supplies can absorb the regenerative energy that recharges the battery and return it to the AC grid with industry-leading efficiency of 96%. Furthermore, robust thermal management incorporated in the EA-10000 Series supplies ensures high reliability.

EA-10000 Series autoranging graph

EA-10000 Series True autoranging characteristic with full power capacity down to 1/3 of the rated voltage and a wide current range​​

Analyzing Critical Inverter Signals

Pulse-width modulation and multi-phase current and voltage waveforms have historically presented challenges for automotive oscilloscopes and the engineers who rely on them. Yet being able to see and measure these waveforms is critical to optimizing an inverter’s reliability, robustness, power density and efficiency.

The introduction of 6 and 8-channel oscilloscopes has made it much easier to study 3-phase systems, but for inverters special measurement techniques are also needed:

  • PWM signals are difficult to trigger on – making it hard to get stable, repeatable measurements. Special attention must be paid to ensure a stable time reference.
  • Analyzing 3-phase systems requires voltage, current, angle and power measurements for individual phases as well as the total system. Phasor diagrams are ideal for observing magnitudes, angles and balance.

Inverter, Motor and Drive Analysis software on 4/5/6 Series oscilloscopes simplifies triggering on PWM outputs and setting up 3-phase measurements. Phasor diagram displays help you visually understand and debug 3-phase electrical problems.

Oscilloscope measurements on traction inverter outputs

3-phase voltage, current and power measurements on an inverter output.

Learn More:

Learn more about using Phasor Diagrams on Oscilloscopes for 3-Phase Power Analysis

Measuring traction inverter electrical parameters under different motor loads

Plots of power parameters over 100 acquisitions, including VRMS, IRMS, true power, phase difference, apparent power and reactive power.

Learn More:

Inverter Motor Drive Analysis Datasheet

Understanding System Behavior Under Changing Motor Loads

In the quest for power density and efficiency, it is important to understand and analyze the dynamic performance of the drive and motor under many different test conditions including:

  • Motor startup
  • Different motor loads
  • Motor stop

Test times can vary from a few seconds to several minutes depending on the test plan. An oscilloscope with long record length stores all of the relevant information during the run and presents the results as waveforms and plots. Capturing high-speed data gives the engineer an ability to zoom into a particular region of the waveform to pinpoint a problem. In contrast, power analyzers typically support calibrated 3-phase measurements, but without access to high sample rate data.

Visibility into Vector Control Parameters such as DQ0​

Closed loop inverter and motor systems use feedback to provide superior control of speed and torque compared to open loop systems. Closed loop “vector” controllers perform real-time computations to transform angular and current feedback into simpler variables (D and Q) which can be linearly scaled in real time. The scaled D and Q parameters are then inverse-transformed to provide input to the modulators used to drive the switches. ​

Since these important calculations occur deep within the controller, it is difficult to study D and Q in relation to other system parameters. The IMDA application on the 5/6 Series B MSOs supports a unique measurement – DQ0 (Direct Quadrature Zero) that helps engineers gain insight into controllers. It mathematically computes D and Q from the inverter’s output waveforms by applying a combination of Park’s and Clarke’s transform. The results are displayed as numeric measurements and as a phasor diagram with a resultant vector. By incorporating encoder angle, engineers can observe DQ0 vectors aligned with rotor magnet zero position when used with the QEI index pulse. These visual tools provide unique visibility into controller performance during actual operation of the motor.

DQ0 vector control parameters measured on an oscilloscope

DQ0 measurements use output waveforms to calculate and display control system coefficients​.

Learn More:

DQ0 Analysis of Motor Control Systems Using an Oscilloscope Whitepaper

Measuring electric vehicle motor torque and speed with an oscilloscope

Acquisition trends and histograms indicate speed variation. Hall sensors are one of the sensor types supported.​

Correlating Mechanical and Electrical Measurements

In order to understand the effects of decisions in electronics and algorithms, engineers must be able to correlate the motor’s mechanical performance with electrical measurements. The motor’s angle, direction, speed, acceleration and torque are key to understanding system performance. Being able to measure both electrical parameters at the input of the traction inverter and the mechanical output of the motor enables engineers to determine overall system efficiency.

Mechanical measurements like speed, direction and angle depend on sensor signals which must be decoded and displayed by the test equipment. Many BLDC motors come equipped with built-in Hall sensors which can be accessed using digital or analog probes. Other systems may rely on QEI (Quadrature Encoder Interface) sensors.

Torque measurements may be performed using a special-purpose torque sensor on the output of the motor. Torque may also be approximated by applying a scale factor to rms current.

With Tektronix IMDA software sensor signals can be decoded, enabling 5 and 6 Series B MSO oscilloscopes to display speed, acceleration, direction, angle and torque.

Understand the Impact of Wide Bandgap Power Device Integration​

The transition to 800 V architectures is unlocking benefits such as lower cable and battery costs, reduced thermal loss and higher system efficiency. SiC MOSFETs are enabling higher switching voltages and lower switching loss, but traditional test plans based on silicon devices no longer apply.

Key challenges in testing wide bandgap semiconductors include:​

  • Current and voltage probing at high power levels
  • Accurately measuring signals on high-side MOSFETs in the presence of very high common mode voltages​
  • Measuring switching loss with standardized tests such as double pulse tests​

Tektronix provides solutions for testing traction inverters based on SiC MOSFETs including oscilloscopes, high voltage differential probes, current probes, optically isolated probes, signal sources and precision power supplies.

Double pulse testing using a function generator and oscilloscope

Double pulse testing software uses consistent automated measurement techniques for Eon and Eoff measurements.

Learn More:

Get more details on double pulse testing

EV traction inverter diagram 5 Series B EA

EV Traction Inverter Testing System

Testing an EV Powertrain design requires an oscilloscope, appropriate probes, signal source, and application software. This system may be customized to suit your application.

We are excited to introduce our traction inverter test system, SOLN-IMDA-EV, engineered for adaptability and accuracy.

Dive deeper into the specifics and discover how our EV traction inverter testing reference solution can be tailored to optimize your powertrain’s performance while ensuring it meets industry standards and regulations.

Instrument/Probe/Option Quantity Description
EA 10000 Series 1 Programmable bidirectional power supplies and regenerative electronic loads
MSO58B-BW1000* 1 1 GHz, 8 Channel Scope
5-PRO-AUTOMOTIVE-3Y 1 Automotive Solution Bundle including Inverter, Motor and Drive Software Analysis Options 5-IMDA, 5-IMDA-DQ0 and 5-IMDA-MECH and decoding for automotive serial buses
THDP0200 3 200 MHz, +/-750 V, high voltage differential probe
TCP0030A 3 120 MHz, 30 Arms, spilt-core AC/DC current probe
TLP058 1 8-channel logic probe
TEKSCOPE-ULTIMATE 1 TekScope PC Software for off-line analysis, including IMDA Analysis and comprehensive serial bus support
TEKDRIVE-STARTER 1 TekDrive Data Storage Subscription, Individual Tier, Annual user license

View The Complete Bench Setup

Testing Tools & Solutions for EV Inverters

5 series B MSO - MSO58B

5 Series B MSO Mixed Signal Oscilloscope

5 Series MSO is a mixed signal oscilloscope with a high definition display with a touchscreen, up to 8 inputs, 12-bit analog-to-digital converters and bandwidth up to 2 GHz.

6 Series B MSO Mixed Signal oscilloscope

6 Series B MSO Mixed Signal Oscilloscope

Troubleshoot and validate high-speed designs with bandwidth that starts at 1 GHz and goes up to 10 GHz.

5 series B automotive 3 phase

EV Traction Inverter Testing

Optimize traction system efficiency and reliability with this oscilloscope-based solution. It enables fast, accurate analysis of the dynamic PWM output of traction inverters.    Increase y …

EA Elektro-Automatik 10000 Series Bidirectional Power Supplies

High-voltage supplies with built-in load to source and sink power at 96% efficiency.

Tektronix AFG31000 function generator


The AFG31000 Series with InstaView™ technology is a high-performance function generatorwith built-in waveform generation applications, patented real-time waveform monitoring, and a modern user interface

IsoVu Isolated Oscilloscope Probes

IsoVu Isolated Probes

Probing systems make high-resolution measurements in the presence of common mode signals or noise.

Glossary of Key Terms for EV Traction Inverters

Traction Inverter: A device that converts the direct current (DC) from the vehicle's battery into alternating current (AC) to drive the electric motor.

PWM Voltage Signals: The outputs of traction inverters are Pulse Width Modulation (PWM) voltage signals. By modulating the pulse width, the inverter control sthe speed and torque of the electric motor.

SiC Power Semiconductors: Silicon Carbide (SiC) power semiconductors are wide bandgap devices used in traction inverters due to their superior properties compared to traditional silicon-based semiconductors. They offer higher efficiency, can operate at higher temperatures, and switch at higher frequencies.

IGBTs and MOSFETs: Insulated-Gate Bipolar Transistors (IGBTs) and Metal-Oxide-Semiconductor Field-Effect Transistors (MOSFETs) are types of transistors used in traction inverters for switching.

FOC: Field-Oriented Control (FOC) is a motor control strategy that optimizes the torque and efficiency of the motor by controlling the angle between the direct axis (D) and the quadrature axis (Q) of the rotor's magnetic field.

Frequently Asked Questions (FAQ)

What is a traction inverter and its role in an electric vehicle?

A traction inverter converts the DC power from an electric vehicle's battery into AC power for the electric motor. It controls the motor's speed, torque, and direction, crucial for vehicle movement and efficiency.

What are the main parameters tested in a traction inverter?

Critical parameters include output voltage and current waveform quality, switching frequency, efficiency, thermal performance, electromagnetic interference (EMI), and response to various load conditions.

What is the role of SiC power semiconductors in traction inverters?

Silicon Carbide (SiC) power semiconductors are increasingly being used in traction inverters due to their superior properties compared to traditional silicon-based semiconductors. SiC semiconductors offer higher efficiency, can operate at higher temperatures, and switch at higher frequencies. This contributes to better overall efficiency of the traction inverter, allowing for more compact designs and improved performance of the electric vehicle.

How is field oriented control used in motor/inverter controllers?

Digital Signal Processing (DSP) algorithms, such as field-oriented control (FOC), are often used in inverter controllers to precisely control the Pulse Width Modulation (PWM) output. These algorithms allow for precise control of the motor’s speed and torque, leading to smoother operation and better efficiency. They also enable the inverter to respond quickly to changes in load demand, improving the overall performance of the electric vehicle.

What are the challenges in analyzing critical inverter signals?

Analyzing critical inverter signals can be challenging due to the high switching frequencies and the complex nature of the signals. For instance, PWM signals can be difficult to trigger on, making it hard to get stable, repeatable measurements. Special measurement techniques and tools are often required to accurately capture and analyze these signals.

How is efficiency testing conducted for traction inverters?

Efficiency testing involves measuring input and output power under different load conditions. Efficiency is calculated as the ratio of output power to input power and helps optimize the inverter's energy conversion. Being able to measure both electrical parameters at the input of the traction inverter and the mechanical output of the motor enables engineers to determine overall system efficiency.

What tools are used for testing of traction inverters?

Oscilloscopes, probes and special analysis software are common tools. They capture waveforms, measure electrical characteristics, monitor temperature, and assess electromagnetic emissions.

How do oscilloscopes assist in traction inverter and motor analysis?

Tektronix high-performance oscilloscope solution enables fast and accurate analysis of the complex and dynamic PWM output of traction inverters, assisting engineers in optimizing traction system efficiency and reliability. Increase your system performance and lower your time-to-market with:

  • 3-phase PWM analysis software including electrical, mechanical, system efficiency and DQ0 measurements. Sensors supported: Hall, QEI and Resolver
  • Oscilloscopes Time Trend plot for analyzing motor start up profile
  • Serial protocol decoding for common vehicle protocols like CAN, LIN, and SENT
  • Arbitrary Function Generator for injecting signals
  • PC-based remote control for operating at a safe distance from high-voltage and rotating devices
  • IMDA solution offers two unique trend plots on the power quality measurement to support such requirements: Time trend plot and Acq trend plot.
  • Acq (Acquisition) trend plots record specific dynamic measurements as motor parameters change over multiple acquisitions.
  • Supports mathematical conversion of Line-Line to Line-Neutral for specific wiring. This is useful when true neutral wiring or probing to this is difficult.
  • Analyze Inverter and Automotive three-phase designs for DC input and AC output wiring configuration.
  • Configure wiring(s) and filters to perform efficiency measurements for a DC-AC topology most suitable for inverter testing.
