TekScope PC Analysis Software

Get the analysis capability of an award-winning oscilloscope on your PC. Analyze waveforms anywhere, anytime. The basic package is free and lets you scale and measure waveforms. Purchased options add advanced capabilities such as multi-scope analysis, bus decoding, power analysis and jitter analysis.

TekScope software is currently available for order in the US, Canada and Mexico.

Register for free TekScope software and learn about premium analysis options.

REGISTER NOW

TekScope PC Analysis Software

Oscilloscope analysis without the oscilloscope

Analyze waveforms just as you would on your scope, without the need for the scope. Work anytime, anywhere.

  • Analyze waveform files from Tektronix oscilloscopes, or other instruments
  • Remotely connect to Tektronix 4/5/6 Series MSOs to acquire data in real time

Share data with your colleagues and customers

Stop sending stacks of static screenshots and send entire datasets instead. Your fellow engineers will be able to rescale waveforms and take measurements as if they were sitting in front of the oscilloscope.

Synch waveforms from two scopes

Turn two scopes into a single virtual instrument. View and analyze data from multiple scopes on the same screen, with a single set of controls.

  • Rearrange channels
  • Group channels
  • Pan and zoom
  • Add cursors or automated measurements
Detail of TekScope PC software decoding an SPI serial bus

Advanced analysis -- even if your scope isn’t equipped for it

Boost the analysis available on your scope with advanced capabilities like bus decoding, spectrum analysis, and jitter analysis.

  • The same intuitive user interface as the 4/5/6 Series MSOs
  • Supports most waveform files (.wfm, .isf, .csv, .h5, .tr0, .trc, and .bin)
  • Flexible licensing lets you add options you need, when you need them.
Option Description Purchasing Details
TEKSCOPE-DECODE Protocol Decode: I2C, I3C, SPI, CAN, CAN-FD, LIN, FlexRay, SENT, 100BASE-T1 Automotive Ethernet, Mil-STD-1553, ARINC-429, RS-232, USB, Ethernet, I2S, LJ, RJ, TDM, SPMI 1-Year License

3-Year License
TEKSCOPE-DJA Jitter Measurements & Analysis 1-Year License

3-Year License
TEKSCOPE-MULTI Multi-Scope Analysis: Remotely connect to multiple oscilloscopes to view and analyze data simultaneously; compatible with 4/5/6/5LP/6LPD Series MSOs 1-Year License

3-Year License
TEKSCOPE-PAM3-BND PAM3 Measurements & Analysis, Automotive Ethernet Signal Separation, Automotive Ethernet 100Base-T1 Protocol Decode 1-Year License

3-Year License
TEKSCOPE-PWR-ELEC Power Electronics: Power Measurements & Analysis, Magnetics Measurements & Analysis 1-Year License

3-Year License
TEKSCOPE-PWR-INTG Power Integrity: DPM Measurements & Analysis, SPMI Protocol Decode 1-Year License

3-Year License
TEKSCOPE-SPECVIEW Spectrum View: spectrum analysis 1-Year License

3-Year License
TekScope Analysis Datasheet

Literature Number: 48W-61673-0
Datasheet
TekScope Waveform Analysis Software Compared to other Tektronix Software Factsheet
This 2-page factsheet compares the features of TekScope waveform analysis software for PCs, to three other analysis packages offered through Tektronix.  It compares the capabilities and features of TekScope to: TekScope Anywhere (no longer …

Literature Number: 61W-61668-0
Fact Sheet
TekScope PC Waveform Analysis Flyer
TekScope software delivers the analysis capabilities of the latest Tektronix oscilloscopes to your PC. Analyze waveforms anywhere, anytime.  This flyer explains how TekScope software helps with greater productivity, advanced analysis, multi-scope …

Literature Number: 61W-61671-0
Brochure
