high speed interface

Higher Data Throughput Than Traditional Methods

Tektronix will be launching a next generation high speed interface (HSI) framework that will allow its customers to move data from its scopes to the users’ PC at speeds 2.5x or higher compared to current VXI-11 ethernet (VISA) connections. When enabled, your scope hosts itself as a high-speed interface server allowing remote clients (PCs) to connect programmatically.

Faster Waveform Transfer

The challenges of overcoming access and inherent latency across multiple channels of measured data are enormous.

Our innovative solutions enables faster waveform transfer based on the unique method of navigating through traditional rest states.

This is ideal for situations requiring ultra precise and repeatable triggering, acquisition of large quantities of waveform sizes such as pulse trains, and/or continuous long record length acquisition.

data access sync

High Speed Interface Connectivity and Sequencing

Reduce Latency

Reducing latency through optimizing API Connectivity is foundational for any high speed, data heavy testing that is being automated.

Tektronix High Speed Interface solution provides a Python or C/C++ environment for easy, reliable configuration of your system baseline.

latency chart

Improve Data Throughput

When fractions of a second of throughput is mission critical, sequencing must be easy to deploy and reliable. This is especially useful when acquiring large quantities of waveform sizes, like pulse trains or other repetitive signal types

Tektronix High Speed Interface solution’s ability to uniquely navigate through rest stages provides improved data throughput, and more efficient test cycle times.

throughput chart

Supported Products

6 Series B MSO Mixed Signal oscilloscope

6 Series B MSO Mixed Signal Oscilloscope

Troubleshoot and validate high-speed designs with bandwidth that starts at 1 GHz and goes up to 10 GHz.

5 series B MSO - MSO58B

5 Series B MSO Mixed Signal Oscilloscope

5 Series MSO is a mixed signal oscilloscope with a high definition display with a touchscreen, up to 8 inputs, 12-bit analog-to-digital converters and bandwidth up to 2 GHz.

6 Series low profile digitizer

6 Series Low Profile Digitizer

  • 4 analog/spectral channels
  • 25 GS/s sample rate
  • 1 GHz to 8 GHz bandwidth (upgradable)
  • Opt. 2 GHz RF HW Digital-Down-Converter
  • Closed Embedded OS or Windows 10 OS
  • Up to 1 Gpts record length
