AFG1000 Arbitrary/Function Generator

AFG1000 Arbitrary/Function Generator

With 25 MHz or 60MHz bandwidth, 2 output channels, 1 mVpp to 10 Vpp output amplitude across full bandwidth, Tektronix AFG1000 Arbitrary/Function Generator generates all kinds of waveforms needed in a lab. Most importantly, it offers the best value for money in the Tektronix line-up of arbitrary function generators.

Base Price
US $850 - US $1,130
Questions? Chat Now
AFG1000 Arbitrary/Function Generator

Features

Benefits

Dual-channel, 25MHz bandwidth with 1mVpp to 10Vpp output; 14-bit vertical resolution and 1uHz frequency resolution Generate more precise waveforms for more accurate lab result.
50 built-in arbitrary waveforms with continuous, modulation, sweep and burst modes Generate all kinds of waveforms needed in a lab.
Dedicated 3.95” TFT LCD display, easy-to-navigate front panel and  menu Provide easy access for users to conduct experiments.
Supported by TekSmartLab™ Make it convenient for educational users to monitor and configure multiple instruments in a lab.
Built-in 200MHz, 6-digit frequency counter Measure frequency/period/pulse width/duty cycle in a precise way without a standalone frequency counter.
Standard 5 year warranty Better user experience guaranteed by Tektronix quality and service.



Models

Model Analog Bandwidth Analog Channels Output Frequency Record Length Sample Rate Vertical Resolution List Price
AFG1022 25 MHz 2 1 uHz to 25 MHz 8k points 125 MS/s 14-bit US $850
Configure & Quote
AFG1062 60 MHz 2 1 uHz to 60 MHz 1M points 300 MS/s 14-bit US $1,130
Configure & Quote
ModelAFG1022
List PriceUS $850
Analog BandwidthAnalog ChannelsOutput Frequency
25 MHz21 uHz to 25 MHz
Record LengthSample RateVertical Resolution
8k points125 MS/s14-bit
ModelAFG1062
List PriceUS $1,130
Analog BandwidthAnalog ChannelsOutput Frequency
60 MHz21 uHz to 60 MHz
Record LengthSample RateVertical Resolution
1M points300 MS/s14-bit
Model Analog Bandwidth Analog Channels Output Frequency Record Length Sample Rate Vertical Resolution List Price
AFG1022 25 MHz 2 1 uHz to 25 MHz 8k points 125 MS/s 14-bit US $850
Configure & Quote
AFG1062 60 MHz 2 1 uHz to 60 MHz 1M points 300 MS/s 14-bit US $1,130
Configure & Quote
ModelAFG1022
List PriceUS $850
Analog BandwidthAnalog ChannelsOutput Frequency
25 MHz21 uHz to 25 MHz
Record LengthSample RateVertical Resolution
8k points125 MS/s14-bit
ModelAFG1062
List PriceUS $1,130
Analog BandwidthAnalog ChannelsOutput Frequency
60 MHz21 uHz to 60 MHz
Record LengthSample RateVertical Resolution
1M points300 MS/s14-bit
