TBS1000 Series digital oscilloscopes enables engineers and educators to view signals with confidence. Each model features digital real-time sampling up to 2 GS/s, familiar, easy to use controls, built-in, context sensitive help system and a standard 5-year warranty. Choose the version that best suits your needs and application, whether two or four channels, R&D or education.

Bandwidth

Up to 200 MHz

Analog channels

2 or 4

Sampling Rate

2 GS/s

Warranty

5 years



TBS1000B

Handle everyday test challenges without challenging your budget.

Thumbnail

The TBS1000B models offer superior signal visibility, measurement accuracy and analysis capability, at a very affordable price.

Using Built-in Fast Fourier Transform (FFT) Spectral Analysis

Highlights

  • 7-inch WVGA display with wide viewing angle
  • 34 automated measurements
  • FFT analysis, waveform math, cursors, dual frequency counters and more
  • Limit test and data logging

TBS1000B-EDU

Educate tomorrow's leading engineers.

Thumbnail

The TBS1000B-EDU helps instructors prepare tomorrow’s engineers for the future with special features for educators.

Highlights

  • Courseware ecosystem lets instructors load information into the TBS1000-EDU, to help students during labs - included standard
  • Compatible with TekSmart Lab™ network software, which helps instructors set up and monitor many instruments from one PC
  • Get help, when and where you need it, with the built-in context-sensitive help system


All classroom and lab resources »



TBS1000

Analyze more signals with ease.

Thumbnail

The TBS1000 allows you to visualize more signals at the same time including more complex signals.

Highlights

  • 4 analog channels
  • 16 automated measurements
  • 5.7-inch color display



Models

Model Description Analog Bandwidth Sample Rate Record Length Analog Channels List Price
TBS1032B

Only available in
North America
and Europe

30 Mhz .5 GS/s 2.5k points 2 US $470
Configure & Quote
TBS1052B-EDU - 50 MHz 1 GS/s 2.5k points 2 US $540
Configure & Quote
TBS1052B - 50 MHz 1 GS/s 2.5k points 2 US $550
Configure & Quote
TBS1072B-EDU - 70 MHz 1 GS/s 2.5k points 2 US $790
Configure & Quote
TBS1072B - 70 MHz 1 GS/s 2.5k points 2 US $890
Configure & Quote
TBS1064 - 60 MHz 1 GS/s 2.5k points 4 US $1,140
Configure & Quote
TBS1102B-EDU - 100 MHz 2 GS/s 2.5k points 2 US $1,140
Configure & Quote
TBS1102B - 100 MHz 2 GS/s 2.5k points 2 US $1,190
Configure & Quote
TBS1152B-EDU - 150 MHz 2 GS/s 2.5k points 2 US $1,490
Configure & Quote
TBS1152B - 150 MHz 2 GS/s 2.5k points 2 US $1,520
Configure & Quote
TBS1104 - 100 MHz 1 GS/s 2.5k points 4 US $1,680
Configure & Quote
TBS1202B-EDU - 200 MHz 2 GS/s 2.5k points 2 US $1,820
Configure & Quote
TBS1202B - 200 MHz 2 GS/s 2.5k points 2 US $1,850
Configure & Quote
TBS1154 - 150 MHz 1 GS/s 2.5k points 4 US $2,050
Configure & Quote
ModelTBS1032B
