Touch the present. Test the future.

5 & 6 Series MSO

With up to 8 channels, the 5 Series MSO gives you unmatched visibility into complex systems.

The 6 Series MSO offers low noise, high resolution, and bandwidth up to 8 GHz for performance designs.

  • 15.6-inch display and pinch/swipe/zoom touchscreen
  • FlexChannel® inputs make MSO easy
  • Upgradeability to fit your needs for years to come
Compare

The first and only scopes with integrated spectrum analyzers

MDO3000/MDO4000C

The versatile MDO3000 allows you to capture analog, digital and RF signals on one scope and gives you the flexibility to add more instruments including a function generator, multimeter, logic analyzer and more. The MDO4000C offers all the above plus unique time correlation for faster insight into your signals.

Compare

Compare and choose your scope

Feature

MDO3000 Series

MDO4000C Series

5 Series MSO

6 Series MSO
Bandwidth 100 MHz, 200 MHz, 350 MHz,
500 MHz, 1 GHz
200 MHz, 350 MHz,
500 MHz, 1 GHz
350 MHz, 500 MHz,
1 GHz, 2 GHz
1 GHz, 2.5 GHz, 4 GHz,
6 GHz, 8 GHz
Analog Channels 2 or 4 4 4, 6 or 8 4
Digital Channels 16 1 16 1 Up to 64 1 Up to 32 1
Sample Rate
(All Channels)
Up to 5 GS/s Up to 5 GS/s 6.25 GS/s 25 GS/s
Display 9 inch WVGA (800x480) 10.4 inch XGA (1024x768) 15.6 inch HD (1920x1080)
w/ Capacitive Touch
15.6 inch HD (1920x1080)
w/ Capacitive Touch
Record Length 10 Mpoints 20 Mpoints 62.5 Mpoints
125 Mpoints 1
62.5 Mpoints
125 Mpoints 1
250 Mpoints 1
Integrated Instruments Oscilloscope
3 GHz Spectrum Analyzer 1
Logic Analyzer 1
Protocol Analyzer 1
Arbitrary/Function Generator 1
Digital Voltmeter 2
Frequency Counter 2
Oscilloscope
3 GHz or 6 GHz Spectrum Analyzer 1
Logic Analyzer 1
Protocol Analyzer 1
Arbitrary/Function Generator 1
Digital Voltmeter 2
Frequency Counter 2
Oscilloscope
Logic Analyzer 1
Protocol Analyzer 1
Arbitrary/Function Generator 1
Digital Voltmeter 2
Frequency Counter 2
Oscilloscope
Logic Analyzer 1
Protocol Analyzer 1
Arbitrary/Function Generator 1
Digital Voltmeter 2
Frequency Counter 2
Applications 1 Aerospace (MIL-STD-1553, ARINC-429)
Audio (I2S, LJ, RJ, TDM)
Automotive (CAN, CAN FD, LIN, FlexRay)
Computer (RS-232/422/485/UART)
Embedded (I2C, SPI)
Limit and Mask Testing
Power Analysis
USB2.0 (LS, FS, HS)
Aerospace (MIL-STD-1553, ARINC-429)
Audio (I2S, LJ, RJ, TDM)
Automotive (CAN, CAN FD, LIN, FlexRay)
Computer (RS-232/422/485/UART)
Embedded (I2C, SPI)
Ethernet (10BASE-T, 100BASE-TX)
Limit and Mask Testing
Power Analysis
RF Triggering
USB2.0 (LS, FS, HS)
Advanced Jitter and Eye Analysis
Aerospace (MIL-STD-1553, ARINC-429)
Audio (I2S, LJ, RJ, TDM)
Automotive (CAN, CAN FD, LIN, FlexRay)
Automotive Ethernet Compliance
Automotive Sensors (SENT)
Computer (RS-232/422/485/UART)
Embedded (I2C, SPI)
Ethernet (10BASE-T, 100BASE-TX)
Power Analysis
Power Management (SPMI)
USB2.0 (LS, FS, HS)
USB2.0 Compliance
Advanced Jitter and Eye Analysis
Aerospace (MIL-STD-1553, ARINC-429)
Audio (I2S, LJ, RJ, TDM)
Automotive (CAN, CAN FD, LIN, FlexRay)
Automotive Ethernet Compliance
Automotive Sensors (SENT)
Computer (RS-232/422/485/UART)
Embedded (I2C, SPI)
Ethernet (10BASE-T, 100BASE-TX)
Power Analysis
Power Management (SPMI)
USB2.0 (LS, FS, HS)
USB2.0 Compliance
Starting From US $3,450 FIND OUT MORE US $7,070 FIND OUT MORE US $13,000 FIND OUT MORE US $23,500 FIND OUT MORE
Feature MDO3000 Series MDO4000C Series 5 Series MSO 6 Series MSO
Bandwidth 100 MHz, 200 MHz, 350 MHz,
500 MHz, 1 GHz
200 MHz, 350 MHz,
500 MHz, 1 GHz
350 MHz, 500 MHz,
1 GHz, 2 GHz
1 GHz, 2.5 GHz, 4 GHz,
6 GHz, 8 GHz
Analog Channels 2 or 4 4 4, 6 or 8 4
Digital Channels 16 1 16 1 Up to 64 1 Up to 32 1
Sample Rate
(All Channels)
Up to 5 GS/s Up to 5 GS/s 6.25 GS/s 25 GS/s
Display 9 inch WVGA (800x480) 10.4 inch XGA (1024x768) 15.6 inch HD (1920x1080)
w/ Capacitive Touch
15.6 inch HD (1920x1080)
w/ Capacitive Touch
Record Length 10 Mpoints 20 Mpoints 62.5 Mpoints
125 Mpoints 1
62.5 Mpoints
125 Mpoints 1
250 Mpoints 1
Integrated Instruments Oscilloscope
3 GHz Spectrum Analyzer 1
Logic Analyzer 1
Protocol Analyzer 1
Arbitrary/Function Generator 1
Digital Voltmeter 2
Frequency Counter 2
Oscilloscope
3 GHz or 6 GHz Spectrum Analyzer 1
Logic Analyzer 1
Protocol Analyzer 1
Arbitrary/Function Generator 1
Digital Voltmeter 2
Frequency Counter 2
Oscilloscope
Logic Analyzer 1
Protocol Analyzer 1
Arbitrary/Function Generator 1
Digital Voltmeter 2
Frequency Counter 2
Oscilloscope
Logic Analyzer 1
Protocol Analyzer 1
Arbitrary/Function Generator 1
Digital Voltmeter 2
Frequency Counter 2
Applications 1 Aerospace (MIL-STD-1553, ARINC-429)
Audio (I2S, LJ, RJ, TDM)
Automotive (CAN, CAN FD, LIN, FlexRay)
Computer (RS-232/422/485/UART)
Embedded (I2C, SPI)
Limit and Mask Testing
Power Analysis
USB2.0 (LS, FS, HS)
Aerospace (MIL-STD-1553, ARINC-429)
Audio (I2S, LJ, RJ, TDM)
Automotive (CAN, CAN FD, LIN, FlexRay)
Computer (RS-232/422/485/UART)
Embedded (I2C, SPI)
Ethernet (10BASE-T, 100BASE-TX)
Limit and Mask Testing
Power Analysis
RF Triggering
USB2.0 (LS, FS, HS)
Advanced Jitter and Eye Analysis
Aerospace (MIL-STD-1553, ARINC-429)
Audio (I2S, LJ, RJ, TDM)
Automotive (CAN, CAN FD, LIN, FlexRay)
Automotive Ethernet Compliance
Automotive Sensors (SENT)
Computer (RS-232/422/485/UART)
Embedded (I2C, SPI)
Ethernet (10BASE-T, 100BASE-TX)
Power Analysis
Power Management (SPMI)
USB2.0 (LS, FS, HS)
USB2.0 Compliance
Advanced Jitter and Eye Analysis
Aerospace (MIL-STD-1553, ARINC-429)
Audio (I2S, LJ, RJ, TDM)
Automotive (CAN, CAN FD, LIN, FlexRay)
Automotive Ethernet Compliance
Automotive Sensors (SENT)
Computer (RS-232/422/485/UART)
Embedded (I2C, SPI)
Ethernet (10BASE-T, 100BASE-TX)
Power Analysis
Power Management (SPMI)
USB2.0 (LS, FS, HS)
USB2.0 Compliance
Starting From US $3,450 FIND OUT MORE US $7,070 FIND OUT MORE US $13,000 FIND OUT MORE US $23,500 FIND OUT MORE

1. Orderable option - not included with base instruments
2. Free with instrument registration.

Innovative Extras
  • Industry’s lowest-capacitance passive probes come standard. One for each channel.
  • 3-year warranty, included.  Optional accident protection with Total Protection Plans.
  • DVM and frequency counter free with registration
