Discounts for Education Labs

• 0.0025% DCV accuracy (1 year)
• 1 Msample/s digitizing, 16-bits
• 10-channel scan card option

• Two or three independent outputs
• All outputs displayed simultaneously
• Remote sensing on all channels
• Low noise
• Programmable power supply
• Applications include teaching labs, testing circuit board testing and modules

• 2 or 4 channels up to 500 MHz
• Sample rate up to 2.5 GS/s
• Waveform capture rate of 4 million wfs
• 1.5 inches thick and less than 4 pounds
• Portable with optional battery pack
• Support for multiple communication networks

Applications include education benches, industrial, manufacturing, automotive

The AFG31000 Series with InstaView™ technology is a high-performance function generatorwith built-in waveform generation applications, patented real-time waveform monitoring, and a modern user interface

With the largest display in class, improved low-level signal measurement accuracy and industry-leading probe performance, the 3 Series MDO sets a new standard for bench oscilloscopes

4 Series B MSO is a mixed signal oscilloscope with up to 1.5 GHz bandwidth, HD touch display, serial decoding, digital inputs, frequency and power analysis

• 4 or 6 channels up to 1.5 GHz
• Sample rate of 6.25 GS/s on all analog and digital channels
• Record length up to 62.5 Mpoints
• 12-bit vertical resolution, up to 16 bits in High Res mode
• 13.3-inch HD capacitive touchscreen

Applications include embedded design, power supply testing, automotive, aerospace and defense

High-channel-count oscilloscope for correlating signals across a full subsystem.

• 4, 6 or 8 channels up to 2 GHz
• Sample rate of 6.25 GS/s on all channels
• Record length up to 500 Mpoints
• 12-bit vertical resolution, up to 16 bits in high res mode
• Up to 64 digital channels with logic probes
• High definition display with a touchscreen

Applications include power integrity, inverters and motor drives, automotive, aerospace and defense

Low-noise oscilloscope for validating high-speed designs.

• 4, 6 or 8 channels from 1 GHz to 10 GHz
• Sample rate of 50 GS/s on 2 channels, 25 GS/s on 4
• Record length up to 1 Gpoint on 4 channels
• 12-bit vertical resolution, up to 16 bits at 200 MHz
• Under 55 µV of noise at 1 mV/div and 1 GHz

Applications include signal integrity, serial standards compliance, automotive, radar and wireless

A fully integrated solution to characterize materials, processes and semiconductor devices

Start measuring in minutes without complex programming. Perform I-V characterization and more with this instrument control software for bench instruments and Tektronix oscilloscopes.
