Accelerate I-V Characterization Tests

The Automated TSP Script Generation feature simplifies I-V tests for two-terminal and multi-terminal semiconductor devices, solar cells, and more. You can configure each SMU or PSU for a variety of bias and sweep sourcing operations, then run, edit, and leverage the resulting TSP code.

The Automated TSP Script Generation feature includes:

  • Interactive GUI: Quickly create I-V characterization routines by entering test parameters in a user interface and generate TSP scripts with a single mouse click.
  • Waveform Previews: Verify sourcing behavior prior to generating a script to eliminate the guess work.
TSP Toolkit App Note

Discover how using TSP Toolkit with the MP5000 Series shortens the learning curve and boosts efficiency from validation through production.

DOWNLOAD NOW

MP5000 Series Modular Precision Test System

Applications that Demand Precision and Flexibility

From validation and reliability testing to high-volume production, the MP5000 Series delivers the flexibility, channel density, and automation needed to keep pace with evolving requirements. By combining precision with scalability, it provides a modern foundation for the most demanding workflows—while the broader platform ensures customers can grow into what’s next.

What sets the MP5000 Series Apart

Every detail of the MP5000 Series was designed to help engineers do more with less—less rack space, less downtime, less complexity. Key advantages include:

  • Future-ready modularity – reconfigure in minutes to meet changing needs by mixing SMUs and PSUs within the mainframe
  • High density, compact design – scale up to 6 channels per 1U chassis and connect up to 32 mainframes for parallel, multi-site testing
  • Performance without limits – SMU modules with 100 fA resolution and 1 MSa/s digitization for high-speed capture; PSU modules deliver up to 50 W per channel with bipolar output and advanced protection
  • Automation built in – a test script processor (TSP) eliminates PC-instrument latency with sub-microsecond synchronization across racks; integrates with Python, LabVIEW, and IVI drivers
  • Maximum uptime – module-only calibration, independent slot power control, and intuitive web and touch interfaces keep systems running with less interruption

Would you like more information or talk to one of our experts? Fill in the form to be contacted.

Featured Products

MP5000 mainframe with SMU and PSU modules on the left angled right

MP5000 Modular Precision Test Systems

  • 1U mainframe with 3 slots
  • Up to 6 channels per 1U mainframe
  • Mix & match PSU & SMU



View Product
TSPToolkit__Software_Card_Image_280x210

TSP Toolkit VSCode Extension

Quickly develop Test Script Processor (TSP™) scripts with TSP Toolkit, an open source scripting tool available as a Visual Studio Code (VS Code) extension.

View Product

Related Resources

Technical Brief

Getting Started with the MP5000 Series Modular Precision Test System and Test Automation

Introduction Validation Engineers, Production Test Engineers, and System Integrators are often tasked with developing automated test equipment (ATE) systems, which are widely used for testing various semiconductor devices, such as transistors, diodes …
Technical Brief

Sequencing Power Supply Outputs with the MP5000

Introduction Power supply output sequencing is the process of controlling the order and timing of when voltage is supplied to a device under test (DUT) using multiple power supply channels. Many modern electronic devices, such as ASICs, FPGAs, and mi …
Technical Brief

Advantages of Interlock System on the MP5000 Series

Enabling Safe, Confident Testing in Power Semiconductor and Discrete Device Characterization As voltage and current levels increase to meet the demands of advanced power devices, the risk of electric shock, arc-over, or accidental misconfiguration gr …
