Watch a demonstration of 1000BASE-T (Gigabit Ethernet) transmitter (Tx) testing with a disturber. Gayland Pounder, Tektronix Application Engineer, uses TekExpress Automotive Ethernet software. Hardware includes a Tektronix MSO 5 or MSO 6 Series oscilloscope, a differential probe (TDP 1500 or TDP 3500) and an AFG31102 arbitrary function generator.
Learn more about Tektronix solutions for your Ethernet designs with 1000BASE-T/100BASE-TX/10BASE-T PHY Measurement and Analysis on the 5 or 6 Series B MSO oscilloscope.
Dauer 6:38
