Andrea Vinci's blog

Einträge

KickStart software from Tektronix
Testing and Debugging PMICs with Ease Friday, September 22, 2023
Adaptive Power Optimization is Revolutionizing PMICs “There is no better way to save energy and cut bills than by turning all electronic devices off.” This basic piece of advice is the underlying principle and philosophy behind any form of energy management applied to energy consumption optimization, and in general in so-called adaptive power optimization. In the case of battery powered …
How to Measure a MOSFET I-V Curve
How to Measure a MOSFET I-V Curve Thursday, May 27, 2021
One of the best ways to ensure a MOSFET is functioning properly and meets specifications is to determine its characteristics by tracing I-V curves. There are a number of output characteristics requiring I-V tests; you can derive gate leakage, breakdown voltage, threshold voltage, transfer characteristics, and drain current all by simply tracing I-V characteristics and verifying the device is …
bench power supply
Labornetzgerät Monday, May 17, 2021
Ein Gleichstrom-Tischnetzgerät  ist eine Standardausrüstung für Test- und Messzwecke, das von Elektroingenieuren und Schaltungsentwicklern zur Stromversorgung und zum Testen ihrer Schaltungssysteme im Labor und vor Ort verwendet wird. Wofür genau dient es und wie können Sie das richtige Tischnetzgerät für Ihre Anwendung finden? All das und noch mehr werden wir behandeln. Wofür benötigen Sie …
TBS1000C bench oscilloscope
Was ist ein Oszilloskop? Tuesday, May 11, 2021
Ein Oszilloskop, ursprünglich auch als Oszillograph bezeichnet (umgangssprachlich Scope, Oscope oder O-Scope), ist ein Instrument, das elektrische Signale grafisch darstellt und zeigt, wie sich diese über die Zeit verändern. Es misst diese Signale, indem es mit einem Sensor verbunden wird, der als Reaktion auf physikalische Reize wie Schall, Licht und Wärme ein elektrisches Signal erzeugt. So ist …
Oscilloscope probe connected to a DUT
What is an Oscilloscope Probe? Monday, May 3, 2021
An oscilloscope probe is a device that makes a physical and electrical connection between a test point or signal source and an oscilloscope. Depending on your measurement needs, this connection can be made with something as simple as a length of wire or with something as sophisticated as an active differential probe. Essentially, a probe is some sort of device or network that connects the signal …
Types of signal generators
Types of signal generators Wednesday, April 28, 2021
A signal generator is an analog or digital device that engineers use to create electronic signals when testing circuit designs. There are many different types of signal generators with diverse features and applications. Below are the most common types of signal generators and the unique capabilities of each. Waveform or function generators Waveform generators produce electrical waveforms over a …
Chamber for an EMC/EMI precompliance test
The Financial Case for an EMI/EMC Pre-Compliance Test Solution Tuesday, April 20, 2021
Failing EMI compliance testing can be a design engineer’s worst nightmare. Additional compliance testing costs, external lab testing, debug engineering time, and in some cases, board spins can add significant costs and time delays to your project. Unfortunately, for companies new to EMI/EMC, estimating compliance testing cost can be somewhat challenging. In this blog, we’ll provide information on …
TBS1000C bench oscilloscope
How to Measure Current with an Oscilloscope Tuesday, April 6, 2021
Though it’s not uncommon to measure current with a digital multimeter, measuring current that changes over time requires the use of an oscilloscope. Most oscilloscopes only directly measure voltage, not current, however you can measure current with an oscilloscope, using one of two methods. Measure the voltage dropped across a shunt resistor: Some power supply designs may have shunt resistors …
4200A Electrical Parameter Characterization system controlled from his touchscreen display
MOSFETs Characterization in the Low Power Range Wednesday, March 25, 2020
Introduction The Semiconductor Industry is always searching for new special materials, dielectric solutions, and new device geometries for scaling down the device size further and further. Lateral and vertical heterostructures of 2D materials, for instance, have led to new revolutionary tiny and low-power electronics. A 4200A Electrical Parameter Characterization system controlled from his …
