As network demands increase, long-haul communications are becoming more complex. Signaling has migrated from simple on-off keying to complex modulation formats such as DP-QPSK and PM-16QAM. Advanced test tools are required to test the latest communication systems for 100G, 400G, 1Tb/s and beyond.
Minimize the time to market for your coherent optical design with the Tektronix Tx/Rx solution. Future proof your test system with a scalable solution that is ready for 400G, has superior EVM and BER performance and allows customizable DSP analysis/visualization. Tektronix is the only test and measurement vendor that can offer a complete coherent optical test system from signal generation, to modulation, acquisition, and analysis.
Acquiring and analyzing coherent optical signals can present unique challenges to the engineer. Download your free Technical Brief to understand how to tackle these challenges.
Identifying the cause of coherent optical transmitter and receiver impairments can be challenging. Get the Coherent Optical Reference Poster to help speed your designs.
Learn about the basic technologies used to convert complex modulated optical signals to electrical signals capable of being acquired by an oscilloscope, coherent detection techniques and why real-time or equivalent-time scopes may be chosen, and see a number of equipment configurations that support coherent demodulation and analysis.
|OM4000 Series||The OM4200 Series Optical Modulation Analyzers provide precise detection of 100G and 400G complex modulated signals. Use the powerful included analysis software for complete characterization of coherent optical devices and systems.|
|DPO70000SX Series||The DPO70000SX Series Oscilloscopes provide unprecented flexibility for complex modulated signal acquisition. Configure the system for 100G analysis now, with the flexibility to grow into 400G capability.|
|AWG70000 Series||As multi-level coherent optical signals become more prevalent, the flexibility of an arbitrary waveform generator becomes a requirement. Together with RFXpress, the AWG70000 Series is capable of generating current and next-generation multi-level signals.|
|OM5110 Transmitter||The OM5110 Multi-format Optical Transmitter provides the performance, flexibility, and convenience required for generation of 100G and 400G coherent optical signals. It offers built-in, narrow-linewidth lasers and completely automated or manual modulator bias voltage control.|
|Coherent Analysis Software||The OM1106 Optical Modulation Analysis software offers a complete suite of tests, measurements, and visualizations for a wide variety of coherent optical signals. It provides the user with the capability to completely customize the signal processing to meet a wide range of requirements.|
